NI PXIE-4302输入模块是一款高性能的PXI模拟输入模块，由美国国家仪器公司（National Instruments，简称NI）生产。以下是对该模块的
18185397189
NI PXIE-4302输入模块是一款高性能的PXI模拟输入模块，由美国国家仪器公司（National Instruments，简称NI）生产。以下是对该模块的详细解析：
The NI PXIE-4302 input module is a high-performance PXI analog input module produced by National Instruments (NI). The following is a detailed analysis of the module:
1. Product Overview
Brand and Model: NI PXIE-4302
Product Type: PXI Analog Input Module
Main Function: Provides 32 channels of filtered analog input, suitable for voltage, thermocouple and current measurement.
2. Technical Specifications
Number of channels: 32 channels
Sampling rate: up to 5 kS/s (thousands of samples per second) per channel
Resolution: 24-bit delta-sigma ADC (analog-to-digital converter)
Input range: ±100 mV ~ ±10 V
Digital filter: optional (none, 2 Hz, 20 Hz, 200 Hz, 1 kHz, 2 kHz)
Terminal box options:
TB-4302: for voltage and thermocouple input measurement
TB-4302C: for current input measurement
3. Product Features
High performance: uses 24-bit delta-sigma ADC to provide high-precision analog signal acquisition.
Flexibility: Each channel can independently configure the sampling rate and digital filter to support a variety of sensor inputs.
Synchronization: The high bandwidth of the PXI Express platform allows users to add channels according to application requirements without reducing the sampling rate.
Scalability: NI provides a variety of synchronization solutions to meet the most demanding application requirements.
4. Application scenarios
Laboratory research: suitable for laboratory environments that require high-precision analog signal acquisition.
Industrial Automation: In industrial automation systems, it is used to monitor and control various analog signals.
Test and Measurement: In the field of test and measurement, it is used for data acquisition and signal processing.
