GE FANUC PCIE-5565RC 反射式内存节点卡是Abaco反射内存实时光纤网络产品系列中的一款PCI Express（PCIe）产品，具有高速、灵活
18185397189
GE FANUC PCIE-5565RC 反射式内存节点卡是Abaco反射内存实时光纤网络产品系列中的一款PCI Express（PCIe）产品，具有高速、灵活和易于操作的特点。以下是对该产品的详细介绍：
总之，GE FANUC PCIE-5565RC 反射式内存节点卡是一款功能强大、性能卓越的数据共享解决方案，适用于各种需要高速、实时数据交换的分布式系统。
The GE FANUC PCI-5565RC Reflective Memory Node card is a PCI Express (PCIe) product in Abaco's family of Reflective memory real-time fiber optic networking products, featuring high speed, flexibility and ease of operation. Here is a detailed description of the product:
I. Product overview
Product name: GE FANUC PCI-5565RC Reflective memory node card
Series ownership: Abaco reflective memory real-time fiber network product line
Main interface: PCI Express
Application scenario: It is suitable for distributed systems requiring high-speed and real-time data sharing, such as data acquisition, simulation and training, industrial automation, and electronic communication.
Second, functional characteristics
High speed connection
Serial connection speed: 2.12 Gbaud
Data transfer rate: up to 170 Mbyte/s
Packet size: Support for dynamic packet sizes from 4 to 64 bytes
Low latency
Deterministic transfer rate: Latency between nodes is only 450 to 500 nanoseconds
High reliability
Error management and detection: prevents data loss
Redundancy mode: Optional redundancy mode improves system reliability
Flexibility and extensibility
Number of nodes: Supports a maximum of 256 nodes
Fiber support: Support up to 300 meters of multi-mode fiber and up to 10 kilometers of single-mode fiber
Configuration: Star configuration can be performed using the AC-5595 hosted hub
Memory and storage
On-board SDRAM: Provides 128/256 MB of reflected memory with optional parity
Independent DMA channel: Has a separate direct memory access (DMA) channel
Operating system support
Supports the Windows 2000, Windows XP, Linux, and VxWorks operating systems
3. Technical specifications
Interface standard: Complies with PCI Express 1.0a standard
Onboard resources: x4 channel PCI Express bridge, four universal network interrupts (each with 32-bit data)
Configuration options: Configurable end conversion, suitable for multiple CPU architectures on the same network; PCI PIO window sizes can be selected, from 2 MB bytes to 64 MB bytes to the full installed memory size
4. Application advantages
Bus-independent design: Protecting current network infrastructure investments
High Performance application deployment: Low latency, deterministic data transfer rates enable predictable high performance application deployment
Seamless integration: Seamless integration with GE Fanuc Intelligent Platforms' SBC solutions and most industry standard products
5. Use and maintenance
Hardware installation: Insert the reflective memory card into the PCI Express slot of the computer and connect the individual nodes by optical fiber
Software installation: Install the reflective memory card driver and configure the related parameters
Maintenance and upgrades: Provide field-upgradeable firmware to adapt to changing application requirements
In summary, the GE FANUC PCI-5565RC Reflective Memory Node card is a powerful, high-performance data sharing solution for a variety of distributed systems requiring high-speed, real-time data exchange.
