ABB 3BSE042237R2 PP836A 控制面板

ABB 3BSE042237R2 PP836A 控制面板是一款由ABB公司生产的工业控制设备，广泛应用于工业自动化领域。以下是对该控制面板的详细解析：

一、基本信息

• 品牌：ABB
• 型号：PP836A（3BSE042237R2）
• 类型：操作面板/触摸屏PLC模块

二、技术规格

1. 显示特性：
• 可提供最多50个四行音讯，每行最多32个字符的最大可视化功用。
• 支持“Ticker-文本”、条形图或输入/输出状况切换等功能，进一步增强显示效果。
• 显示屏尺寸为61×33毫米，白色可控背光，对比度可调。
2. 输入与按键：
• 配备6个标准输入按钮和4个附加功能输入按钮，用于直接输入到程序代码。
• 支持作为“基本”相同的10种菜单语言和相关的字符集。
3. 电源与功耗：
• 供电电压可选12V DC或24V AC/DC，许用范围为10.2至28.8V DC或20.4至26.4V AC（47至63 Hz）。
• 在不同电压下的功耗分别为：24V DC时典型值65mA，12V DC时典型值40mA，24V AC时典型值90mA。
4. 物理尺寸与安装：
• 开孔尺寸（宽x高x深）为119.5 x 78.5 x 1.5–4.0 mm，用于安装配电屏。
• 总体尺寸为128.2 x 86 x 38.7 mm。
5. 环境适应性：
• 工作环境温度范围为0～50℃，相对湿度≤90%。
• 在配电盘上正确安装情况下符合IP65防护等级。

三、功能特点

1. 高精度与稳定性：
• 采用高速16位A/D转换器，测量数据稳定，重复性好。
• 自动程控电流源技术，电流源共设1000个电流档位，由内部微控制器根据被测电阻自动控制，从而达到比较宽的测量范围。
2. 智能化设计：
• 高度智能化设计，功能设置巧妙先进，可自动判断测试线虚接、断线等故障。
• 保护功能完善，能可靠保护反电势对仪器的冲击，具有自动放电指示功能。
3. 用户友好性：
• 全部汉字菜单及操作提示，直观方便。
• 支持多种菜单语言和字符集，满足不同用户需求。

四、应用场景

ABB 3BSE042237R2 PP836A 控制面板适用于各种工业自动化控制系统，如DCS（分散控制系统）、PLC（可编程逻辑控制器）系统等。它可用于监控和控制工业过程中的各种参数，如温度、压力、流量等，为工业自动化提供可靠的数据支持和操作界面。

ABB 3BSE042237R2 PP836A control panel is an industrial control device produced by ABB, which is widely used in the field of industrial automation. The following is a detailed analysis of the control panel:

1. Basic information

Brand: ABB

Model: PP836A (3BSE042237R2)

Type: operation panel/touch screen PLC module

2. Technical specifications

Display characteristics:

It can provide maximum visualization function of up to 50 four-line audios and up to 32 characters per line.

Support functions such as "Ticker-text", bar graph or input/output status switching to further enhance the display effect.

The display size is 61×33 mm, with white controllable backlight and adjustable contrast.

Input and buttons:

Equipped with 6 standard input buttons and 4 additional function input buttons for direct input into program code.

Supports the same 10 menu languages and related character sets as "Basic".

Power supply and power consumption:

The power supply voltage can be selected as 12V DC or 24V AC/DC, with an allowable range of 10.2 to 28.8V DC or 20.4 to 26.4V AC (47 to 63 Hz).

The power consumption at different voltages is: 65mA typical at 24V DC, 40mA typical at 12V DC, and 90mA typical at 24V AC.

Physical size and installation:

The opening size (width x height x depth) is 119.5 x 78.5 x 1.5–4.0 mm for installing the distribution board.

The overall size is 128.2 x 86 x 38.7 mm.

Environmental adaptability:

The working environment temperature range is 0 to 50℃, and the relative humidity is ≤90%.

It meets the IP65 protection level when properly installed on the distribution board.

III. Functional features

High precision and stability:

Adopting a high-speed 16-bit A/D converter, the measurement data is stable and the repeatability is good.

Automatic program-controlled current source technology, the current source has a total of 1000 current gears, which are automatically controlled by the internal microcontroller according to the measured resistance, so as to achieve a relatively wide measurement range.

Intelligent design:

Highly intelligent design, ingenious and advanced function settings, can automatically judge the test line virtual connection, disconnection and other faults.

The protection function is perfect, which can reliably protect the impact of the back electromotive force on the instrument, and has an automatic discharge indication function.

User-friendliness:

All Chinese menus and operation prompts are intuitive and convenient.

Support multiple menu languages and character sets to meet the needs of different users.

IV. Application scenarios

ABB 3BSE042237R2 PP836A control panel is suitable for various industrial automation control systems, such as DCS (distributed control system), PLC (programmable logic controller) system, etc. It can be used to monitor and control various parameters in industrial processes, such as temperature, pressure, flow, etc., and provide reliable data support and operation interface for industrial automation.
