ABB 1SVR040000R1700 信号转换器

产品简介

ABB 1SVR040000R1700信号转换器是一款功能强大的通用模拟信号转换器，广泛应用于工业自动化领域。以下是关于该信号转换器的详细解析：基本信息品牌：A

产品型号：

更新时间：2024-08-05

厂商性质：

访问量：

产品咨询 18185397189

产品分类

tel-phone

18185397189

article

技术文章

详细介绍在线留言

ABB 1SVR040000R1700信号转换器是一款功能强大的通用模拟信号转换器，广泛应用于工业自动化领域。以下是关于该信号转换器的详细解析：

基本信息

品牌：ABB
型号：1SVR040000R1700
产品类型：CC-U/STD通用信号转换器
应用场景：控制系统、工业自动化、PLC等

技术规格

额定电源电压：24-48伏DC
精度：满量程的0.1%
响应时间：较短（具体数值可能因应用而异，但通常非常快速）
尺寸：12.0 x 2.25 x 10.5厘米（长x宽x高）
重量：0.125千克
工作温度范围：

常规范围：-20°C至+60°C
扩展范围：-40°C至+80°C（具体取决于应用环境）

输入信号：多种类型可选，包括但不限于0.9毫安至55毫安电流信号、45毫伏至11伏电压信号等
输出信号：同样支持多种类型，如0至55毫安电流信号、0至11伏电压信号等

功能特点

多种配置选项：据称可能有120多种配置，满足不同应用场景的需求
电气隔离：提供3路电气隔离，确保信号传输的安全性和稳定性
可配置输出信号响应：在输入信号中断时，可以配置为低故障安全或高故障安全输出信号响应
快速信号传输：非常适合用于需要快速响应和精确控制的应用场景
防短路信号输出：内置防短路保护功能，确保在短路情况下不会损坏设备

应用场景

ABB 1SVR040000R1700信号转换器适用于多种工业自动化应用场景，包括但不限于：

控制系统中的信号转换和传输
机器和设备的测试平台
高频模拟信号的监控和快速切换
其他需要精确信号控制和转换的工业自动化系统

1SVR040000R1700 (1).jpg

The ABB 1SVR040000R1700 signal converter is a powerful universal analog signal converter that is widely used in the field of industrial automation. The following is a detailed analysis of the signal converter:

Basic information

Brand: ABB

Model: 1SVR040000R1700

Product type: CC-U/STD Universal Signal Converter

Application scenarios: control system, industrial automation, PLC, etc

Technical specification

Rated power supply voltage: 24-48 V DC

Accuracy: 0.1% of full scale

Response time: Short (the exact number may vary by application, but is usually very fast)

Dimensions: 12.0 x 2.25 x 10.5 cm (L x W x H)

Weight: 0.125 kg

Operating temperature range:

Normal range: -20°C to +60°C

Extended range: -40°C to +80°C (depending on application environment)

Input signals: Various types are available, including but not limited to current signals from 0.9 MA to 55 MA, and voltage signals from 45 mA to 11 volts

Output signals: Also supports a variety of types, such as 0 to 55 MA current signals, 0 to 11 volts voltage signals

Functional characteristics

Multiple configuration options: It is said that more than 120 configurations are possible to meet the needs of different application scenarios

Electrical isolation: Provides 3 ways of electrical isolation to ensure the safety and stability of signal transmission

Configurable output signal response: When the input signal is interrupted, the output signal response can be configured to be low or high fault safe

Fast signal transmission: Ideal for applications requiring fast response and precise control

Anti-short circuit signal output: built-in anti-short circuit protection function to ensure that the device will not be damaged in the case of short circuit

Application scenario

The ABB 1SVR040000R1700 signal converter is suitable for a variety of industrial automation applications, including but not limited to:

Signal conversion and transmission in control systems

Test bed for machines and equipment

High frequency analog signal monitoring and fast switching

Other industrial automation systems that require precise signal control and conversion
